XRAY 370008 X12 2018 US Specs  [XR-370008]

XRAY 370008 X12 2018 US Specs
Price:
AUD$510.99
Brand:
XRAY
Model:
XR-370008
Please kindly input your name and email address, we will inform you once we have the restocking.
Or you may find similar product under the
R/C Models - On-Road - Pan Cars category
Write a review
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"
alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"

Dimensions

  • Class: 1/12 electric pan car
  • Width: Adjustable 167mm +/- 2mm front side, 169mm rear
  • Length: 264mm (varies predicated on back tires used)
  • Wheelbase: 201 +/-0.5mm
  • Weight: 202 g
  • Ready-to-run fat: 840 g - incl. BL system (varies predicated on equipment used)


Chassis

  • Chassis: EU edition - 2.5mm carbon fibre, CNC machined; United States version - 2.0mm Swiss 7075 T6 aluminum, CNC machined
  • Body: perhaps not included, uses 1/12 pan car kind


Drivetrain

  • Type: 2WD direct drive to rear axle
  • Rear Axle: Graphite shaft with ball differential
  • Primary: Spur/pinion
  • Bearings: High-speed ball-bearings (10)


Suspension

  • Front: Spring-supported, kingpin-style front suspension with upper & reduced suspension system fingers and steering blocks
  • back: Articulating back engine POD adjustable via pivot-ball links, managed by rear surprise absorber.
  • Rear Shock: Central adjustable oil-filled shock absorber


Geometry

  • Ride Height: Adjustable front + right back
  • Wheelbase: Adjustable
  • Camber Adjustable front
  • Front Caster (Static): 1–14.5° static adjustable fixed caster
  • Front Caster (Reactive) 2.5–7.5° adjustable reactive caster
  • Track-width: Adjustable front part and rear
  • Toe: Adjustable front
  • Downstop: Adjustable rear
  • Ackermann: Adjustable with shims
  • Bumpsteer: Adjustable with shims
  • Steering: Direct linkage between steering servo saver and steering obstructs
  • Balance: Front/rear weight balance adjustable via battery spot


Other

  • Wheels: maybe not included
  • Tires: perhaps not included
  • Instructions: Full-color guide with 3D visuals
  • Set-up guide: Printed variation maybe not included. Latest full-color Set-up guide (16 pages) are installed from XRAY web site. Set-up Book shows previous XRAY models in photographs contained within it, even so the methodology and set-up theory are exactly the same for several 1/12 pan vehicles.
  • Packaging: Carton box with synthetic bags with parts
  • Additionally included: HUDY Diff Grease, Authentication Certificate, components list & exploded view, decals, oils
  • Not included: Motor, batteries, price controller, tires, human anatomy, steering servo, radio gear, tools
