Special Design for 1/10th, 1/8th Crawlers
The dependable equipment coupled with effective software (features a range of
programmable parameters like begin force, drag braking system price, and etc.)
creates an ideal power way to 1/10th, 1/8th stone crawlers.
Adjustable PWM Frequency & Advanced DEO/Freewheeling Technology
The adjustable PWM regularity along side advanced level DEO/freewheeling technology
guarantees users great throttle linearity and driving feel.
Relevant to any or all Weather Conditions
The waterproof and dust-proof design allows the WP-Crawler-Brushed
to be utilized in most weather conditions without any issue of
damage triggered towards ESC from water or debris.
Exemplary Braking Performance
Hobbywing's revolutionary, fine-tunable drag stopping system price and adjustable drag braking system and braking system force
significantly enhance the brag braking system and invite users to have the exceptional braking performance.
Super Internal BEC
The integrated switch mode BEC with a maximum production of 6A and voltage
adjustable between 6V and 7.4V permits using different standard servos,
high voltage servos and also other peripherals.
15 Programmable Parameters
The WP-Crawler-Brushed, which features 15 programmable parameter services and products,
does connect with different cars and songs.
Separate Programming/Fan Port
The split PRG/FAN port on the ESC can power an outside fan to maximise ac
performance or link the ESC to a Light-emitting Diode system field for ESC development.
a Light-emitting Diode Program Box is Included
A standard, committed Light-emitting Diode system industry (included in the package) allows users to
plan the WP-Crawler-Brushed effortlessly.
Item Specification
Type
- Scale : 1/8th & 1/10th
- Brushed/Brushless : Brushed
- Waterproof : Waterproof
Specifications
- Cont./Peak Current : 80A/400A
- Input Voltage : 2-3S Lipo/5-9 Cell NiMH
- BEC production : change Mode: 6V/7.4V@3A
Wires & Connectors
- Input Wires : Red-14AWG-200mm*1 / Black-14AWG-200mm*1
- Output cables : Blue-14AWG-200mm*1 / Yellow-14AWG-200mm*1
- Input Connectors : XT60 Connectors
- Output Connectors : No
ESC Programing via
- SET Button on ESC : Supported
- LED Program Box : Supported
- LCD Program Box : maybe not Supported
- WiFi Module : perhaps not Supported
- Program Port : Separate Program Port
Firmware
- Firmware Upgrade : maybe not Supported
Size & Weight
- Size : 36.2x31.6x17.0mm
- Weight : 58.5g (w/Wires)
Applications
- Motors : Brushed motor (540/550/775 size engines)
- Vehicles : 1/8th,1/10th Rock Crawlers
- KV Rating/T Count : Brushed motor limitation with 2S LiPo/6S NiMH: ≥10T or RPM<30000@7.4V
Brushed Motor Limit with 3S LiPo/9S NiMH: ≥16T or RPM<20000@7.4V
