HOBBYWING 80060160 Mini 12A Aircraft ESC  [HW-80060160]

HOBBYWING SkyWalker 12A - 80060160
Price:
AUD$17.99
Brand:
Hobbywing
Model:
HW-80060160
Condition:
Brand New
Write a review
alt="HOBBYWING SkyWalker 12A - 80060160" title="HOBBYWING SkyWalker 12A - 80060160"
alt="HOBBYWING SkyWalker 12A - 80060160" title="HOBBYWING SkyWalker 12A - 80060160"
alt="HOBBYWING SkyWalker 12A - 80060160" title="HOBBYWING SkyWalker 12A - 80060160"
alt="HOBBYWING SkyWalker 12A - 80060160" title="HOBBYWING SkyWalker 12A - 80060160"
alt="HOBBYWING SkyWalker 12A - 80060160" title="HOBBYWING SkyWalker 12A - 80060160"
alt="HOBBYWING SkyWalker 12A - 80060160" title="HOBBYWING SkyWalker 12A - 80060160"
alt="HOBBYWING SkyWalker 12A - 80060160" title="HOBBYWING SkyWalker 12A - 80060160"
alt="HOBBYWING SkyWalker 12A - 80060160" title="HOBBYWING SkyWalker 12A - 80060160"

Compact Power Control with the HOBBYWING 80060160 ESC

For pilots needing compact, reliable throttle control, the HOBBYWING 80060160 Aircraft ESC delivers a tidy package. It is aimed at model flyers who prioritise straightforward installation and consistent motor response.

Supports Brushed and Brushless Motor Types

This ESC works with both brushed and brushless motors, offering broad application across different electric models. It accepts 2-3S LiPo inputs and is rated for 12A continuous current with a 15A peak for transient loads.

Quick Field Tuning with Familiar Tools

Programming is achievable via your transmitter or with the LED program card for rapid tuning between flights. There is no provision for firmware upgrades, though the factory presets cover essential throttle and protection settings.

Specifications

  • Cont./Peak Current: 12A/15A
  • Input: 2-3S LiPo
  • BEC Output: Linear mode: 5V, 1A
  • Output Wires: Black-20AWG-100mm*3
  • Size: 38.0x18.0x6.0mm
  • Weight: 9g

The HOBBYWING 80060160 offers a compact, no-nonsense ESC option for pilots who want 12A continuous output and easy programming. It fits well in small to medium electric aircraft.

Yes. Its 12A continuous rating and 15A peak make it suitable for many small sport electrics and foam models when matched to the correct motor and prop.
Use your radio transmitter or the LED program card to change settings like braking and start mode. This makes quick adjustments possible at the flying site.
The linear BEC supplies 5V at 1A, which will power small servos and the receiver. For heavy servo setups consider a separate BEC or external power source.
The ESC measures 38.0x18.0x6.0mm and weighs 9g, so it fits behind small cowlings and inside narrow fuselages with careful cable routing.
