Tamiya made 1/10 F104 Pro II with Body (58652) RWD drivetrain On-Road Formula Cars assembly kit
Present day Racer
This R/C formula chassis installation kit is sold with a realistic polycarbonate body drawing on 2017 trends with a razor-sharp, slanting nose and bulging side pontoons. Additional parts are included to produce alternative tapered reduced parts for part pontoons. The complex front wing and its own low rear counterpart are reproduced with split components, because are bargeboards and induction pod.
Streamlined & Upgraded Chassis
The kit fits the lightweight and streamlined F104 chassis with different upgraded parts. In front, the separate kingpin coil springtime suspension's camber may be changed by switching top mount attachment way, even though the rear rigid setup features a T-bar for smooth pitch damping, in conjunction with friction dishes and a TRF damper. Back tires may be changed without the necessity to dismantle the aluminum ball differential. Semi-pneumatic artificial rubber tires give great realism. Comes with complete ball bearings.
Specifications
Length: 440mm, Width: 180mm, Height: 88mm Wheelbase: 270mm Tread: 150mm (Front), 145mm (back) Tire Width/Diameter: 30/64 (Front), 35/64 (back) FRP Double Deck Frame Transverse engine Rear Direct Drive 2WD Ball Differential Symmetrical Steering Tie-Rod Suspension: Kingpin Coil Spring (front side), T-Bar Rigid (backside) Gear Ratio 4.16:1 (whenever used in combination with 25T Pinion and 104T Spur Gears Requires Type 540 Motor and Electronic Speed Controller (sold separately)
Separately needed Things
engine 2-Channel R/C Unit with ESC battery power & Charger R6/AA/UM3 batteries for transmitter
