Tamiya 58652 F104 Pro II Formula Racing Chassis Kit with Body  [58652]

Tamiya 58652 - F104 Pro II (with Body)
Price:
AUD$225.57
Brand:
Tamiya
Model:
58652
GTIN:
4950344586523
Please kindly input your name and email address, we will inform you once we have the restocking.
Or you may find similar product under the
category
Write a review
alt="Tamiya 58652 - F104 Pro II (with Body)" title="Tamiya 58652 - F104 Pro II (with Body)"
alt="Tamiya 58652 - F104 Pro II (with Body)" title="Tamiya 58652 - F104 Pro II (with Body)"
alt="Tamiya 58652 - F104 Pro II (with Body)" title="Tamiya 58652 - F104 Pro II (with Body)"
alt="Tamiya 58652 - F104 Pro II (with Body)" title="Tamiya 58652 - F104 Pro II (with Body)"
alt="Tamiya 58652 - F104 Pro II (with Body)" title="Tamiya 58652 - F104 Pro II (with Body)"
alt="Tamiya 58652 - F104 Pro II (with Body)" title="Tamiya 58652 - F104 Pro II (with Body)"

Performance and Style: Tamiya F104 58652 for Track Use

Enthusiasts who favour sharp handling and authentic formula styling will appreciate the Tamiya F104 58652. The polycarbonate body reflects current aerodynamic thinking while keeping the slanted nose and side pontoons that define this class of model.

Chassis Engineering for Better Control

The F104 chassis is engineered for low weight and predictable response, prized in club and club-level competition. Enhanced parts in this kit improve robustness and tuning range. The independent kingpin coil spring front setup allows camber adjustment via the upper mount, and the rear T-bar plus TRF damper smooths pitch movements for more composed driving.

Fast Maintenance and Authentic Look

Thanks to the aluminum ball differential, rear wheel servicing is quick and straightforward, helping you get back on track faster. The semi-pneumatic synthetic rubber tyres maintain a realistic profile and steady contact on sealed circuits, supporting both practice sessions and race weekends.

Specifications

  • Length: 440mm
  • Width: 180mm
  • Height: 88mm
  • Wheelbase: 270mm
  • Tread: 150mm (Front), 145mm (Rear)
  • Tire Width/Diameter: 30/64 (Front), 35/64 (Rear)
  • Frame: FRP Double Deck
  • Drive: Rear Direct Drive 2WD
  • Differential: Ball Differential
  • Suspension: Kingpin Coil Spring (Front), T-Bar Rigid (Rear)
  • Gear Ratio: 4.16:1 (with 25T Pinion and 104T Spur Gears)
  • Motor Requirement: Type 540 Motor (sold separately)

The Tamiya F104 58652 brings a balance of historic form and modern handling that appeals to tuners and racers who want a responsive, compact formula machine.

You will need a Type 540 motor, an ESC compatible with your motor choice, a steering servo, receiver and a suitable battery pack to complete the kit and make it drivable.
Begin with factory ride height and neutral camber, then test a few laps and tweak front camber and T-bar tension. Small changes give clear feedback on handling balance.
After-market upgrades exist for springs, dampers and mounting hardware to refine handling. Choose upgrades that match your driving style and track conditions.
Check drivetrain components, clean dust from bearings and inspect suspension points. Replace worn tyres and recheck gear mesh and differential lubrication regularly.
