Hobbywing 30401061 XERUN-3652SD 6100KV Track Tunable Motor  [HW-30401061]

HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061
Price:
AUD$0.00
Brand:
Hobbywing
Model:
HW-30401061
Please kindly input your name and email address, we will inform you once we have the restocking.
Or you may find similar product under the
category
Write a review
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"

Track-Ready Hobbywing XERUN-3652SD for 1/10 Scale Cars

The Hobbywing XERUN-3652SD-6100KV-D5.0-G2 is a compact sensored brushless unit aimed at serious 1/10 scale racers. Its 6100KV rating delivers a quick top end while keeping steering inputs responsive.

Balanced Power for Controlled Drives

This 4-pole motor is tuned to give steady torque and a linear throttle curve that helps with corner exit control. The motor's no-load current is 5.9A and resistance is 2.9 mOhm, supporting efficient performance across runs.

Adjustable Timing for Surface Matching

With timing adjustable from 20 to 40 degrees you can adjust the motor character to suit high-grip asphalt or lower traction surfaces. Small timing changes let you prioritise either acceleration or higher top speed.

Specifications

  • KV Rating: 6100
  • LiPo Cells: 2S
  • No-load Current: 5.9A
  • Resistance: 2.9mΩ
  • Outer Diameter: 36mm (1.417in)
  • Length: 52.5mm (2.067in)
  • Shaft Diameter: 5mm (0.197in)
  • Weight: 186g (6.56oz)
  • Shaft Length: 15mm (0.591in)
  • Timing: 20-40 Degrees (Adjustable)

A reliable upgrade for club racers and weekend competitors, the Hobbywing XERUN-3652SD brings tunable speed and predictable control to 1/10 scale platforms.

For the smoothest launches and consistent low-speed control use a sensored-compatible ESC. Sensorless setups can work but may lose some low-end refinement.
This motor is specified for use with 2S LiPo packs. Avoid higher cell counts to prevent excessive RPM and potential overheating of the motor and ESC.
Follow the manufacturer's procedure for timing adjustment, make small changes and test on track, and monitor motor and ESC temperatures during each run.
Its linear power and timing options can be used in drift cars, but you may prefer lower KV or different gearing depending on the style of drifting you run.
